High Load Capacity Full Electric Pallet Stacker With Mast Stable Operation

2 ton high load capacity electric pallet stacker with imported mast at high lifting height 5.6m

Quick Details:

Description: full electric pallet stacker

Capacity: 2000kg

Max. lifting height: 5600mm

Free lift: 1940mm

Aisle width for pallets 800*1200 lengthways: 2515mm

Travel speed, laden/unladen: 5.8/6km/h

Lifting speed, laden/unladen: 0.09/0.11m/s

Lowering speed, laden/unladen: 0.12/0.11m/s

Battery: 24V300AH

Advantages:

​ Safety and Productivity

• ​​​AC Motor eliminates replacement of carbon brush, make maintenance very convenient.
• The multi-function display instrument has power display, fault indication, working time cumulative display and fast slow display.
• The side door and the battery cover can be opened. The battery can be pulled out from the side to facilitate the exchange and maintenance of the battery.
• It has shock absorbers to reduce noise.
• Emergency reversing device in the handle provides higher safety for the whole operation.
• The automatic deceleration function makes the operation safer.

Optimum Structural Design

• ​​​Low center of gravity ensures the stable operation.
• Vertical driving wheel ensures convenient maintenance and small turning radius. Water-proof and dust-proof motor structure, keeps the braking and motor more durable and reliable.
• The frame and mast are dividable and exchangeable.
• Full free lifting. fit for working in low roof house.

Serviceability

• ​​​Low voltage protection setting prolongs the battery use time.
• The electronic components' concentrated design simplify the circuit and makes easy access to assemble, debug and maintain.
• CANbus technology reduces wiring comlexity and increase reliability.
• Hall element reduces wear components, resulting in increased component life.

Option:

• ​​​Adjustable forks.
• Straddle legs.

straddle pallet stacker

walk behind pallet stacker
