Straddle Legs Electric Walkie Forklift , Adjustable Electric Powered Forklift

Name: Straddle Legs Electric Walkie Forklift Adjustable Electric Powered Forklift
Brand: REACH
Price: 1 USD

China Straddle Legs Electric Walkie Forklift , Adjustable Electric Powered Forklift wholesale

Brand Name : REACH

Model Number : CTDR12

Certification : CE, TUV

Place of Origin : Zhejiang, China

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 200 sets per month

Delivery Time : 25 - 30 days

Packaging Details : Nude

Capacity : 1200kg

Load center : 500mm

Lifting height : 1600/2500/3000/3300mm

Lowered fork height : 70mm

Fork size : 35/100/1070(1150)mm

Drive speed, laden/unladen : 5.3/5.6km/h

Lift speed, laden/unladen : 0.06/0.13m/s

Lower speed, laden/unladen : 0.13/0.1m/s

Contact Now

Straddle legs with adjustable forks warehouse forklift trucks electric walking type

Quick Details:

Model: Warehouse forklift trucks with straddle legs CTDR12
Capacity: 1200kg
Lift height: 1600/2500/3000/3300mm
Fork dimensions: 35/100/1070(1150)mm
Turning radius: 1575mm

Travelling speed, laden/unladen: 5.3/5.6km/h

Lift speed, laden/unladen: 0.06/0.13m/s

Lower speed, laden/unladen: 0.13/0.1m/s
Battery: 24V120Ah

Advantages:

Structural And Safety

Side handle with emergency reverse switch, ensure operator safety.
Built in unloading valve, ensure the warehouse forklift truck is not overloaded, improve reliability.
Emergency power-off switch, stepless speed control.
With side cover and battery cover both can be opened, the battery can be pulled out from side way for exchange, charging and maintenance.
The warehouse forklift trucks is stable and the center of gravity is low.
Vertical driving wheel with small turning radius and the wheel is easy to change and maintain.
Motor is dustproof, waterproof, more durable.
The balance wheel is adjustable structure, more stable and reliable.

Serviceability

Low voltage protection system.
The lines are neat and beautiful, assembly, debugging, maintenance convenience.
CANbus technology.
Holzer sensor electronic components to reduce wear and prolong the service life.

SPECIFICATIONS
Model		CTDR12-III
Load capacity	kg	1200
Load center distance	mm	500
Load distance, centre of drive axle to fork	mm	795
Fork height, lowered	mm	70
Tyre size, front	mm	250*70
Tyre size, rear	mm	98*82
Additional wheels (dimensions)	mm	150*60
Height, mast lowered	mm	2145/1895/2145/2295
Free lift (option 2500-3500mm)	mm	~
Max. lifting height	mm	1600/2500/3000/3300
Height, mast extended	mm	2145/3145/3645/3995
Height of tiller in drive position min./max.	mm	670/1300
Overall length	mm	2015
Length to face of forks	mm	890
Overall width	mm	1182-1582
Fork dimensions	mm	35/100/1070(1150)
Width overall forks	mm	200-800
Aisle width for pallets 800*1200 lengthways	mm	2420
Turning radius	mm	1575
Travel speed, laden/unladen	km/h	5.3/5.6
Lift speed, laden/unladen	m/s	0.06/0.13
Lowering speed, laden/unladen	m/s	0.13/0.10
Battery	V/Ah	24/120
Service weight	kg	780/800/820

Straddle Legs Electric Walkie Forklift , Adjustable Electric Powered Forklift
